Dot Matrix Blue 12864 Lcd Display Yellow Green 5v With Backlight

  • 1
  • 2

Brand Name : OKSMART

Model Number : OKM12864-227D

Certification : SGS

Place of Origin : Shenzhen China

MOQ : 1000

Price : USD 1.3-2.0 per piece

Payment Terms : Trade Assurance, L/C, T/T, Western Union, MoneyGram, D/P, D/A

Supply Ability : 90000 pieces per month

Delivery Time : 30-45 working days

Packaging Details : Kraft box / white box to a carton or customized packing

Other name : LCD screen 12864 blue screen / yellow green

Dot size : 0.42mm(L)*0.42mm(W)

Dot pitch : 0.44mm(L)*0.44mm(W)

Viewing area : 61.0mm(L)*31.5mm(W)

Module size : 75mm(L)*43.6mm(W)*5.1mm(H)

Storage temperature Tstg : -20~+70 °C

Contact Now

LCD screen 12864 blue screen / yellow green 5v LCD screen with backlight

OKM12864-227D graphics dot-matrix liquid crystal display module, which is mainly composed of row driver and column driver, can display 128 (column) × 64 (row) dot matrix. Can complete the graphic display.

OKM12864-227D control instructions, and CPU interface using 8-bit data bus parallel input and output mode.

OKM12864-227D can directly interface with 80 series 8-bit microprocessor.

OKM12864-227D can be graphically, textually, graphically and textually displayed, as well as feature display in text mode, as well as graphical copy operations.

OKM12864-227D used in industrial instrumentation, medical equipment and other fields

Module size:

75mm(L)*43.6mm(W)*5.1mm(H)

Viewing area:

 61.0mm(L)*31.5mm(W)
Dot pitch: 0.44mm(L)*0.44mm(W) Dot size: 0.42mm(L)*0.42mm(W)
Operating temperature Topr: -10~+60 °C Storage temperature Tstg: -20~+70 °C

Dot Matrix Blue 12864 Lcd Display Yellow Green 5v With BacklightDot Matrix Blue 12864 Lcd Display Yellow Green 5v With Backlight
